Valve Connections and 2 Wire Digital Output Devices | Standard Automation

ARP Logo - Header

Connecting standard output devices is usually straight-forward. They connect directly to the dual level terminal blocks in the control panel. The bottom row contains the neutral (or negative) reference wire connection. The top row is the output signal from the PLC that actuates the output device.

Below is a typical solenoid valve din connector wiring diagram.  Refer to the manufacturer’s installation instructions for specific wiring diagrams per your application.
